University of Louisville eBike

University of Louisville eBike

Shop our Collegiate Exclusive eBike for the University of Louisville.

$1,699.00
$1,699.00
Sale Sold out
Color: White

Product Highlights

  • Sleek, durable, single die-cast foldable magnesium frame with no unsightly soldering joints.
  • Portability at only 47 lbs, with an intelligent quick-release mechanism for easy storage, foldable pedals, and handlebar.
  • One size fits all adults, height range 4'9" to 6'2"
  • UL certified by UL solutions meeting standards ANSI/UL 2849 & UL 2271
  • Blaupunkt 36V 350W rear wheel hub motor, 50 Nm torque and maintenance free.
  • Magnetic closure system to securely keep the bike folded during transportation.
  • Roller blade-style wheel at the bottom of the folded frame for enhanced portability.
  • High-quality disc brakes for reliable stopping power.
  • 6-speed Shimano SIS circuit for smooth gear shifting.
  • 20-inch puncture-resistant, 2.125 tires for worry-free rides.
  • Pedal assist with a 3-stage control, adjustable via the LCD bike computer, reaching speeds up to 32 km/h (20 mph).
  • Throttle assist control conveniently located on the hand grip, allowing speeds up to 20 mph (32 km/h).
  • Li-ion battery with a capacity of 36 V/10.5 Ah, ensuring a short charging time.
  • Removable and lockable battery case located inside the frame.

Technical Specifications

  • Frame: Single die-cast magnesium (60 x 22 x 41")
  • Rims: Black magnesium
  • Tires: 20" x 2.125
  • Gears: Shimano 6-speed SIS derailleur (44T/14T-28T)
  • Brakes (front/rear): Disc brakes, 160mm front / 180mm rear
  • Headset: Semi-Integrated
  • Maximum riding weight: 265 lbs (120 kg)
  • Motor: Integrated in the rear wheel, DC 36V/350W, 40~45 Nm, brushless, maintenance-free
  • Battery: 36V/10.5 Ah LG lithium-ion battery with integrated BMS (Battery Management System)
  • Controller: 36V/15A DC
  • Sensors: Cadence & speed sensor
  • Driving modes: 3 levels of pedal and throttle assist
  • Bicycle computer: LC display with three function keys, backlight. Functions: speed, ODO, TRIP, TIME, PAS LEVEL, battery, light, auto power off, error display
  • Charger: Wide range power pack (AC 100 - 240 volts), 42V, 2A
  • Charging time: About 4-6 hours
  • Range: Up to 44 miles (70 km)*
  • Top speed (supported): Max. 20 mph (32 km/h)

Lighting & Reflectors

  • Front LED headlight with integrated reflector, powered by bicycle battery
  • Rear-mounted standard reflector, reflecting pedals, reflecting strips on tire walls

Dimensions & Weight

  • Size (ready to ride): Approx. 60 x 22 x 41" (1520 x 570 x 1040 mm) (LxWxH)
  • Size (folded): Approx. 31.5 x 20 x 23.5" (800 x 500 x 600 mm) (LxWxH)
  • Wheel Size: 20" x 2.125"
  • Handlebar height: 13.4" (340mm)
  • Handlebar width: 22" (560 mm)
  • Head tube length: 4.3" (108mm)
  • Stand over height: 18" (457mm)
  • Saddle height: min 32" max 40" (813 - 1,016mm)
  • Seat post tube: Ø 1.23" (31.6 mm)
  • Wheelbase: 40" (1016 mm)
  • Ground clearance: 8" (200 mm) (up to the transport roller)
  • Frame height: 24" (600 mm)
  • Weight (including battery): Approx. 47 lbs (21 kg)
  • Battery weight: Approx. 5 lbs (2 kg)

Comes Inside Box

  • Folded Blaupunkt eBike
  • Charger with plug
  • Rear reflector to attach to seat post
  • Front and Rear Mudguards for self-assembly
  • Lithium battery in case with 2 keys
  • User manual

Downloads

Is your Blaupunkt eBike the correct size? See size and fit here.

The range with one battery charge depends on various factors, such as support level used, driving speed, physical fitness and personal performance of the rider, shifting behavior (if gearshift is available), road conditions, wind conditions, seating position, system weight, and temperature.

View full details

MAGNESIUM
ALLOY

44 MILE
RANGE

CLASS 2
(20 MPH)

47 LBS
(W / BATTERY)

ROLLER
WHEEL

SINGLE
DIE-CAST MOLD

An eBike with Character

No matter what adventure you have in store, the Blaupunkt electric bike will take you there. For over 100 years, we have been a leader in innovative designs and precision manufacturing. Blaupunkt utilizes our decades of knowledge and experience to produce the highest quality e-Bike on the market today.

Shop Classic

Not looking for a customized NCAA college bike? Check out our iconic, classic styles instead - Fiene, Fiete and Henri.

View Classic eBikes

Blaupunkt x Winnebago

Blaupunkt e-Bikes and well-known RV manufacturer Winnebago have come together to offer customers the ultimate outdoor experiences. You can now purchase Blaupunkt’s top-quality, foldable electric bicycles through authorized Winnebago dealers.

Learn More

One Bike, Endless Adventures

Our compact electric bikes are easily transported without any special carriers or extra equipment needed. Blaupunkt utilizes 100 years of manufacturing knowledge to build the perfect electric bicycle for you. See some biker-conscious features below:

Quality Frame Design

The Blaupunkt e-bike boasts a frame made of premium magnesium alloy, crafted from a single die-cast mold. This innovative process renders the frame sleek, refined, and lightweight.

LCD Display Computer

Our e-bike is equipped with an easy-to-read LCD computer that allows you to choose from 3 levels of motor speed, catering to your specific riding preferences. The LCD computer also provides essential information like battery life, route details, speed, and more. Additionally, you have the option to completely deactivate the motor power.

Powerful Engine

Our Blaupunkt 36V 350W rear wheel hub motor offers impressive speed control with 50 Nm torque. Paired with our efficient LG lithium-ion cells and removable battery housed in the frame, it creates an ideal combination. The motor is maintenance-free, and the integrated BMS in our battery ensures a consistent energy supply.

Folding Made Quick & Easy

Featuring an intelligent clamping mechanism, our bike folds effortlessly in just 4 steps. Once folded, it measures a compact 32x20x24 inches, weighing only 47 lbs. (21 kg). This makes it ultra-portable for convenient transportation on buses or trains, and easily storable when you reach your destination.

Worry-Free Cruising

Equipped with 20" x 2.125" puncture-resistant tires, providing durability and peace of mind. Paired with high-quality disc brakes for reliable stopping power, the Blaupunkt eBike provides worry-free cruising throughout your journey.
